设计简介
端盖的冲孔、翻边、落料、级进摸的设计
摘要
分析了端盖的冲压工艺性，详细介绍了级进模排样方案和总体结构设计，阐述了有关零部件的设计计算方法，以及这套模具所采用的工序—冲孔、翻边、落料。实践证明, 该模具结构灵活、可靠，能保证产品质量，对此类零件的级进模设计有参考价值。
关键词：端盖、冲孔、翻边、落料
Abstract
Has analyzed the end cover ramming technology capability, in detail introduced the level enters the mold row of type plan and the overall structural design, elaborated closes the spare part the design calculation method, as well as this set of mold uses the working procedure - punch holes, the flange, fall the material. The practice proved, This mold structure nimble, is reliable, can guarantee the product quality, the kind of components level enters the mold design to have the reference value regarding this.
Key word: The end cover, the punch holes, the flange, fall the material
