设计简介
[摘要] 酚醛树脂有良好的力学性能和耐热性能，尤其具有突出耐瞬时高温烧蚀性能。利用复合材料制作的桥塞卡瓦代替铸铁卡瓦，其独特的材料主要由玻璃纤维和环氧树脂粘合而成，提高了桥塞的可钻性和耐蚀性，延长使用寿命，节省钻铣和打捞时间。制造卡瓦时采用现代模具加工技术，选用压模成型。在卡瓦本体固化成型之前压入牙齿，解决了以前预留孔与卡瓦连接的困难，实现卡瓦的批量生产。研究难点在于牙齿为是陶瓷材料，而压入时，陶瓷的强度不够，须用玻璃纤维增强的酚醛树脂在外面包裹一层，以使牙齿达到强度要求，如何包上树脂重点。这里在牙齿外面套上一层树脂环，采用物理固定的方法，加上合适的工艺，能将复合材料的桥塞卡瓦增强提高很多，实现70MPa压差的复合材料。
关键词：复合材料、玻璃纤维增强的酚醛树脂、桥塞卡瓦、压模设计
[Abstract]: Phenolic resin has good mechanical properties and heat resistance，especially, the outstanding resistance to high temperature ablation. The bridge plug slip by composite materials instead of cast iron，its unique material is mainly composed of glass fiber and epoxy resin adhesive. Improve the bridge plug can be drilled and corrosion resistance，increase of service life of slip，Saving drilling and milling and fishing time. Manufacturing the slips by modern mold processing technology, selection of compression molding .Press in the teeth in compression molding before slip body curing, solved the difficulties reserving of hole and slip connection previously,realization of slip mass production. Study on the difficulty lies in the teeth as ceramic materials, and indentation, ceramic strength is not enough, must be phenolic resin reinforced with glass fiber coated with a layer of outside, so that the teeth meet strength requirements, how to package resin key. Here in the teeth are covered by a layer of resin ring, using the method of physical fixed, plus the appropriate process, the bridge plug slip by the composites improve a lot, may realize composite 70MPa differential pressure.
Keywords: composite materials, glass fiber reinforced phenolic resin, bridge plug slip by, die design
目录
任务书 I
开题报告 III
指导老师审查意见 IX
评阅教师评语 X
答辩会议记录 XII
中外文摘要 XIII
1 前言 1
2 复合桥塞原理与意义 2
2.1初识复合材料桥塞 2
2.2结构原理 2
2.3分层施工作业程序 6
3 复合材料的基本特性 8
3.1复合材料的结构 8
3.2复合材料的特性 9
3.3复合材料的应用 12
3.4 我国复合材料科学的研究现状 13
4 复合材料卡瓦加工方案 16
5 复合材料卡瓦结构与压模模具设计 16
5.1复合材料卡瓦结构 16
5.2 压模模具设计 17
6 卡瓦压模加工工艺 21
6.1成型前的准备 21
6.2 压缩成型过程 24
6.3塑件的后处理 25
7 模具结构设计 26
7.1关于短玻璃纤维环氧树脂的概述 26
7.2 压力机的选用 27
7.3 施压方向和分型面确定 29
7.4 模具基本结构和脱模方法 30
7.5 模具尺寸设计 30
7.6 成型零件设计 32
7.7导向机构设计 33
7.8 型腔的侧壁和底版厚度的计算 33
7.9 脱模机构设计 33
7.10 牙齿的设计 33
8 参考文献 34
9 设计小结 36
10致谢 37
关键词：复合材料、玻璃纤维增强的酚醛树脂、桥塞卡瓦、压模设计
