设计简介
转子轴承盖冲压成形工艺与模具设计
摘要
本设计的产品为冲压件，主要工序为拉深、冲孔和落料三种工序。设计内容包括：冲压件工艺分析，拉深的计算，排样设计，计算冲压力及冲压设备的选择，模具零件主要工作部分尺寸计算，编制模具主要零件加工工艺规程，模具的装配与调试。
该模具为级进模，包含了拉深、冲孔、落料等工序。凹模，凸模采用整体式结构，安装方便。条料在送料方向上采用导料板导料，利用导料销控制导料步距。卸料装置采用刚性卸料装置。
该设计中使用CAD绘制装配图和零件图，设计说明书也用Microsoft Word排版打印而成，软件的使用提高了设计效率，同时也是设计干净、整洁。
关键词：多工位级进模、凸模、凹模。
The rotor bearing cap forming craft and the die design
Abstract
This design product is a pressing part, the main working procedure for the drawing, the piercing and the blanking three working procedures.The design content includes: The pressing part craft analysis, the drawing computation, arranges the type design, the computation ramming strength and the ramming equipment choice, the mold components prime task partial size computation, establishes the mold major parts processing technological process, the mold assembly and the debugging.
This mold enters the mold for the level, containing the drawing, the piercing, blanking working procedures and so on.The punch, the die uses the integral-type structure, the installment is convenient.The strip material uses in the feeding direction leads the yard lumber to lead the material, the use leads the material to sell controls guides the material step the distance.The stripping device uses the rigid stripping device.
In this design uses the CAD plan assembly drawing and the detail drawing, the design instruction booklet also uses Microsoft the Word typesetting printing to become, the software use enhanced the rated capacity, simultaneously also is the design is clean, is neat.
Key word: The multi-location progressive die, punch, die.
目录
1.绪论 1
1.1冲压概述 1
1.1.1冲压的概念 1
1.1.2冲压的特点 1
1.1.3冲压成型的应用 2
1.1.4冲压的基本工序及模具 2
1.2冲压技术国内外的现状及发展方向 3
1.2.1冲压成形理论及冲压工艺方面 3
1.2.2冲压在冲模设计方面 4
1.2.3冲压设备和冲压生产自动化方面 6
1.2.4冲压标准化及专业化生产方面 7
2.冲压件工艺分析 8
3.拉深的计算 9
3.1计算毛坯尺寸 9
3.2检查能否一次拉成 10
3.3确定凸凹模圆角半径 11
3.4拉深件的拉深高度的计算 11
3.5凸模与凹模间隙的确定 11
4.排样设计 12
4.1排样、计算条料宽度及确定步距 12
5.计算冲压力及冲压设备的选择 13
5.1计算工序冲压力 13
5.2确定压力中心 14
5.3冲压设备的选择: 15
6.模具零件主要工作部分尺寸计算 16
6.1冲模和拉深模刃口尺寸及公差的计算 16
6.2确定各主要零件结构尺寸 18
6.3校核冲压设备基本参数 19
7.编制模具主要零件加工工艺规程 20
7.1凹模加工工艺规程 20
7.2落料凸模加工工艺规程 21
8.模具的装配与调试 22
9.总结 24
致谢 25
参考文献 26
