摘 要
本文分析了滑板的工艺特点，其中包括利用CAD软件进行工件展开图的尺寸计算、工件的工艺分析、冲裁力的计算、模具设计的难点，确定了级进模的排样方案和模具总体结构。该级进模有冲裁、空位、拉伸等9工位。详细介绍了凸模、凹模、固定板、卸料装置等零部件的设计和制造，以及压力机的选择。同时阐述了模具的工作过程、各成形动作的协调性、以及凸模和凹模镶块的装配间隙
关键词   级进模  工艺分析  模具设计 冲裁 拉伸
Abstract
The structural characteristic of a filter mask was analyzed , and the forming technology program of the filter mask was determined. The design of layout in single-row and with few scraps was stated in detail and the total structure and characteristic of multi-position progressive die for filter mask were introduced. The strip materials were precisely oriented by side edge and pilot pin. A rapid and efficient blanking effect was achieved and the quality requirements were met.
keywords : multi-position progressive die ;layout; die structure; technical analysis
