Abstract: The design of the loading material, tensile modulus and single composite processes Piercing Die Design. This paper briefly outlined the Stamping Die current development status and trends. Identify the product of a detailed analysis and the process. Stamping die design in accordance with the general steps to calculate and design the sets on the main mold parts, such as: Terrace die、Cavity die、Punch-holder、Dunn age、Die holder、Stripper、 Jig、Pin stop、Pilot and so on. Die-standard model planes, to choose a suitable stamping equipment. Design work on the parts and specifications will press for the necessary checking calculation. Punch and Die blanking punch were different plate fixed to facilitate adjustment gap; Punch and Die blanking die is used overall fixed plate.  Blanking punch contents is a derivative sales, and guarantee the work piece and the shape of the holes in the relative position accurately, improve processing accuracy. So the structure is designed to ensure reliable operation of die stamping products and the requirements of large-scale production.
Keywords: Combination die；Stamping die tool；Standard die set；Stamping Equipment；Check；Blanking.

 目  录
1 绪论 1
1.1 冲压加工的作用和地位 1
1.2 研究设计的目的和任务 2
1.3 资料及工具准备 6
2 分析零件的工艺性 7
3 确定工艺方案 9
3.1 计算毛坯尺寸 9
3.2 确定工艺方案 12
4 主要工艺参数的计算 13
4.1 确定排样、裁板方案 13
4.2 落料拉深复合模工艺参数计算 15
4.2.1 落料拉深工艺 15
4.2.2 初选压力机 18
4.2.3 计算凸、凹模刃口尺寸及公差 18
4.3 冲孔模工艺参数计算 21
4.3.1 冲压力的计算 21
4.3.2 模具压力中心的确定 22
5 落料拉深模具的结构设计 23
5.1 模具工作部分尺寸计算 23
5.1.1 落料凹模 23
5.1.2 拉深凸模 23
5.1.3 凸凹模 24
5.2 落料拉深模具结构设计 24
5.2.1 模架的选用 24
5.2.2 模具的闭合高度 25
5.2.3 压力机技术参数的校核 25
6 冲孔模主要零件的设计 25
6.1 定位方式的选择 25
6.2 推件装置的选取 26
6.3 导向方式的选择 26
6.4 冲孔凸模的设计 26
6.5 模架及其它零部件的设计 26
6.6 闭模高度的计算 27
结  论 28
致  谢 29
参考文献 30
