铜垫片冲压成形工艺与模具设计
摘要：本设计题目为垫片冲裁模，体现了典型冲裁模的设计要求、内容及方向，有一定的设计意义。通过对该模具的设计，加强了设计者对冲裁模设计基础知识的理解和运用，为设计更复杂的冲裁模具做好了铺垫。
本设计运用冲裁工艺及模具设计的基础知识，首先分析了板材的性能要求，为选取模具的类型做好了准备；然后计算了冲裁件的冲裁力，便于选取压力机吨位及确定压力机型号；最后分析了冲裁件的特征，便于确定模具的设计参数、设计要点及卸件装置。
本设计采用了冲孔—落料复合模成形垫片。成形原理可划分为三个阶段：首先冲孔凸模与凹模共同作用先冲出四个
5mm，而后利用第一步冲出的四个
5mm孔做精确定位使外形凸模与凹模共同作用使工件落料成形，最后一步是进行折弯。
关键词：冲孔—落料复合模 冲孔凸模 凹模 压力机吨位
Abstract：The topic for the design is pad blanking die design,It has manifested the typical blanking die
The design has utilize blanking craft and the basical knowledge of the mold design, has first analyzed the property requirement of the plate , has prepared for selecting the mold type；then has calculated the blanking strength,has advantaged to select the press tonnage and determine press model; Finally has analyzed the characteristic of the products, has advantaged to finite the mold design variable,the design main point and shedder.
This design used piercing and blanking progressive die to form the products.The forming principle can be divided to two stages: First, piercing punch and die affect together and pierce four holes of
3.2mm and one hole of
8.5mm,then use the four holes and the one hole as pinpoint to make the product formed.
Key word: Piercing and blanking progressive die Piercing punch Press Tonnage
摘要：本设计题目为垫片冲裁模，体现了典型冲裁模的设计要求、内容及方向，有一定的设计意义。通过对该模具的设计，加强了设计者对冲裁模设计基础知识的理解和运用，为设计更复杂的冲裁模具做好了铺垫。
本设计运用冲裁工艺及模具设计的基础知识，首先分析了板材的性能要求，为选取模具的类型做好了准备；然后计算了冲裁件的冲裁力，便于选取压力机吨位及确定压力机型号；最后分析了冲裁件的特征，便于确定模具的设计参数、设计要点及卸件装置。
本设计采用了冲孔—落料复合模成形垫片。成形原理可划分为三个阶段：首先冲孔凸模与凹模共同作用先冲出四个
5mm，而后利用第一步冲出的四个5mm孔做精确定位使外形凸模与凹模共同作用使工件落料成形，最后一步是进行折弯。关键词：冲孔—落料复合模 冲孔凸模 凹模 压力机吨位
Abstract：The topic for the design is pad blanking die design,It has manifested the typical blanking die
s design request, the content and the direction, has certain design significance.Through the design of the component mold, strengthens the designer’s understand and utilize to the blanking die design basical knowledge,has prepareed for designing more complex blanking die.
The design has utilize blanking craft and the basical knowledge of the mold design, has first analyzed the property requirement of the plate , has prepared for selecting the mold type；then has calculated the blanking strength,has advantaged to select the press tonnage and determine press model; Finally has analyzed the characteristic of the products, has advantaged to finite the mold design variable,the design main point and shedder.This design used piercing and blanking progressive die to form the products.The forming principle can be divided to two stages: First, piercing punch and die affect together and pierce four holes of
3.2mm and one hole of8.5mm,then use the four holes and the one hole as pinpoint to make the product formed.Key word: Piercing and blanking progressive die Piercing punch Press Tonnage
