设计简介
题目 离心泵的设计及其密封
摘要：在当今社会离心泵的应用是很广泛的,在国民经济的许多部门要用到它。在供给系统中几乎是不可缺少的一种设备。在泵的实际应用中损耗严重，特别是化工用泵在实际应用中损耗，主要是轴封部分，在输送过程中由于密封不当而出现泄漏造成重大损失和事故。轴封有填料密封和机械密封。填料密封使用周期短，损耗高，效率低。本设计使用机械密封。主要以自己设计的离心泵为基础，对泵的密封进行改进，以减少损耗，提高离心泵寿命。本设计其主要工作内容如下，自己设计一台扬程为40m，流量为100m
/h的离心泵。电机功率为7.5kw，转速为2900r/min，.在0—80
C工作环境下输送带杂质液体的离心泵的机械密封。
关键词： 泵 填料密封 离心泵 机械密封
Centrifugal pump design and sealing
Abstract: In today's society, the centrifugal pump is applied widely in the national economy, many departments should use it. In the supply system is almost an indispensable equipment. The practical application in pump industry, especially with serious loss in actual application of pump shaft seals, mainly is loss in the process of conveying, due to improper seal leakage caused heavy losses and accidents. Shaft seals have packing seal and mechanical seal. Packing seal use short cycle, the loss is high. Efficiency is low. This design USES mechanical seal. Mainly in their design based on centrifugal pump, and the improved seal pump, in order to reduce loss, improve the centrifugal pump life. This design is the main content of work, design a head for 40 MB, flow 100m/h of centrifugal pump. Electric power is 7.5 kw, speed for 2900r/min, the 0-80 C work environment impurity liquid conveyer belt of centrifugal pump mechanical seal.
Keywords: pump packing seal centrifugal pump mechanical seal
