设计简介
摘 要
混凝土搅拌机是施工机械装备中的重要设备,其产品质量和生产效率直接影响着建筑施工质量和建筑施工进度。强制式搅拌机是应用最普遍、使用率最高的混凝土搅拌机。双卧轴搅拌机是新型搅拌机型，因其搅拌质量好，生产率高，被广泛用于各种搅拌场合。
本毕业设计从搅拌的目的和机理出发。工作时,物料在叶片推动下沿螺旋面移动,由于两轴的旋转方向相反,两轴间的物料产生挤压、翻滚和揉搓,以达到搅拌混合效果。长期的生产实践证明,通过对卧轴式搅拌机的叶片结构和曲面形状进行合理的布置和设计，混凝土的质量和生产效率会有很大的提高。
结合三种叶片的优点，通过对他们进行有序、合理的布置，让混凝土在有限的时间进行尽可能的搅拌。对它们曲面形状进行理论分析和一些试验，克服传统搅拌机器的缺点，并注意到新型设计可能引起的新的问题。通过搅拌过程的分析，详细阐述了各参数的设计，并结合理论分析，给出了结论和建议。
关键词：混凝土搅拌机；双卧轴； 改进型叶片
ABSTRACT
Concrete mixer is the key device of construction machinery and equipment. It has product quality and production efficiency, which direct impacts on the construction quality and progress of construction. Compulsory mixer is the most common and the highest utilization rate of concrete mixers。Double horizontal shaft mixer is a new-style mixer, which is widely used in many conditions because of the high mixing quality and productivity
This paper begins with the mechanism and purpose of mixing. The materials leaves along the spiral of mobile on the work. Because of the two axis of rotation opposite direction, the materials between the two axis produces extrusion rolling and scrubbing, in order to meet the stirring mixed effect. It has been proved in the long-term production, through the horizontal Coaxial mixer surface of the leaf structure and shape of a reasonable layout and design, concrete’s quality and production efficiency will be greatly improved
Combining with the advantages of three leafs, Concrete is going to mix as much as possible in the limited time through their orderly, rational layout. I do some theoretical analysis and a number of tests for the leaf-surface’s shape. Though the new design test, it overcomes shortcomings of traditional mixer, and notes that the new design may cause new problems. Though the theoretical analysis of the mixing process and concretely explicating the parametric design .Finally, it gives conclusions and suggestions
Key words: concrete mixer; double horizontal shaft; improved blade
