设计简介
三角包装袋形式的液体立式成型－充填－封口包装机设计
成型－充填－封口包装机是能够完成包装容器的成型，充填，封口的机器。按其功能可以分为袋成型－充填－封口包装机和热成型－充填－封口包装机两大类型。其中立式袋成型―充填―封口包装机是包装机械中应用最广泛，批量最大的机型之一，其特点是被包装材料的供料筒设置在制袋器内侧，制袋与充填物料由上到下沿竖直方向进行。该成型机器主要由计量装置，传动系统，横封和纵封装置，成型器，充填管及薄膜牵拉供送机构等部件组成。本次设计的包装机为三角包装袋形式的液体立式成型－充填－封口包装机，选用翻领式成型器，机械无级调速装置，高频加热式横封器，纵封牵拉滚轮通过传动，执行机构实现包装机的包装参数要求。
关键词：包装机，计量装置，成型器，机械无级调速装置
Title The Design of Triangular Form of Liquid Packaging
Bags Vertical Shaped-filling-sealing Packaging Machine
Abstract
Shaped-filling-sealing packaging machine is a machine which can model，fill，seal of the packing container。It can be divided into
two types by the function ,including bag modeling packing machine and hot modeling packing machine. The upright sack modeling― filling― sealing packing machine is the most applicative type. The character of this type of packing machine is as following .The material canister is in the bag making ware ，and bag making and atling is completed from top to bottom . This machine is mostly composed of metering device，transmission agent，crosswise and vertical envelop device，former，stowing pipe and film hauling and pulling feed deliver mechanism. The packing machine designed now is upright sack modeling― filling― sealing packing machine for paper cornucopia bag . In this machine ,there is lapel type former，mechanism infinite speed variation device，dielectric heating crosswise enveloping ware and the truck of vertical enveloping.
keywords packaging machine ,metering device, former, infinite speed variation
目 录
引言 1
1 成型－充填－封口包装机概述 2
1.1 成型－充填－封口包装机的发展概况 2
1.2 成型－充填－封口包装机的分类及特点 2
2 袋成型－充填－封口包装机 3
2.1 分类及组成 3
2.2 立式袋成型－充填－封口包装机 3
3 立式袋成型－充填－封口包装机典型部件设计 4
3.1 三角袋成型器的设计 4
3.2 机械无级调速装置 9
3.3 高频加热式横封器 10
3.4 纵封牵拉滚轮 10
3.5 总体布局图 12
4 设计数据计算 12
4.1 确定主轴转速 14
4.2 轴的设计 14
4.3 选择电动机 16
4.4 蜗轮减速器的设计 17
4.5 锥齿轮的设计 21
4.6 V带设计 24
4.7 双联滑移齿轮设计 26
毕业设计总结 30
致 谢 31
参考文献 32
