摘    要

随着农业种植规模化，机械化，水稻插秧机在农业机械中占有极为重要的地位，高性能插秧机是与当今世界插秧机设计，制造技术接轨的高新技术。本设计是基于洋马AP4步行式插秧机为原型，设计插秧机的插植部分。为保证水稻栽植的顺利进行，栽植运动的插植部分系统设计至关重要。本文对插植结构进行结构分析设计和计算，得到合理的机构参数，为插秧机的精确插植设计提供依据。

关键词：插秧机，插植部，设计，机构


The hand transplanter planting design

Abstract:Along with the agriculture planting scale, mechanization, rice transplanting machine in agricultural machinery occupies a very important position, high performance rice transplanter is with the current world rice transplanter design, manufacturing technology integration of high-tech. The design is based on AP4race walking type rice transplanter for prototype, design of rice transplanter transplanting part. In order to ensure the smooth rice planting, planting movement of the planting system design is very important. This paper analyses the structure of planting structure design and the computation, obtains the reasonable parameters for rice transplanter, the precise planting design basis

Keywords:rice transplanter, transplanting, design, mechanism
