摘要
民以食为天，现在的人已不仅限于温饱问题，现在追求的是生活质量，生活品质。食品搅拌机的出现悄然改变了人们的生活方式。多功能食品搅拌机集合了搅拌，打鸡蛋，打奶油，和面等多重功能，主要应用于西餐厨房以及烘焙行业如面包房，西饼屋，西点屋，咖啡厅等。本论文主要包括对搅拌机电动机的选择、行星齿轮、搅拌器、轴、锥齿轮等各零部件的设计，以及对各零部件结构的选材、校核，最后完成总装图和零件图。
关键词：搅拌机；锥齿轮；搅拌轴；搅拌器
Abstract
Hunger breeds discontentment, now people have not been limited to the problem of food and clothing, now is the pursuit of quality of life, quality of life. The emergence of the food mixer has quietly changed the way people live.. Multifunctional food stirring machine set stirring, beat eggs, whipped cream, and the surface of the multiple functions, mainly used in food in the kitchen and baking industry such as bakery, bakery, pastry shop, coffee shops and so on.This thesis mainly includes all the parts of the choice of the stirring motor, a planet gear, a stirrer, a shaft, a bevel gear design, and the parts structure material, check, the final completion of assembly drawing and parts drawing.
Keywords: Blender; Bevel gears; Stirring shaft; Agitator
 目 录 4.5轴承的选择 - 25 -
4.5.1轴承的型号 - 25 -
4.5.2滚动轴承的配合形式 - 26 -
4.5.3滚动轴承的轴向定位和固定 - 26 -
4.6联轴器的选用 - 26 -
4.6.1选用的联轴器型号 - 26 -
4.6.2联轴器的配合形式 - 27 -
4.7行星齿轮设计 - 27 -
4.7.1行星齿轮各齿轮数据 - 27 -
4.7.2校核齿面疲劳强度 - 28 -
4.8弹簧的设计 - 29 -
第五章 设计小结 - 30 -
参考文献 - 31 -
致谢 - 32 -
