摘    要

本设计是重型卡车主减速器及差速器的设计。主减速器设计时根据给定的基本参数计算出主减速比，根据计算得到的主减速比选取主减速器类型为双级主减速器；与单级主减速器相比，在保证离地间隙相同时还得到很大的传动比，并且还拥有结构紧凑，噪声小，使用寿命长等优点。差速器根据主减速器的设计和以往的经验借鉴选取为结构简单、工作性能平稳、制造方便的对称式圆锥行星齿轮差速器。本设计主要内容包括：双级主减速器和对称式圆锥行星齿轮差速器各个零件参数的设计和校核过程。主减速器结构的选择、主、从动锥齿轮的设计、轴承的校核；差速器结构的选择、行星齿轮、半轴齿轮的设计和校核。
关键词：重型载货汽车；双级主减速器；差速器；齿轮；校核
  This design is designs a structure to the truck to be reasonable, work related reliable two-stage main gear box. This two-stage main gear box is composed of two level of gear reductions. Compares with the single stage main gear box, when the guarantee ground clearance is the same may obtain the very great velocity ratio, and also has the structure to be compact, the noise is small, service life long and so on merits. This article elaborated the two-stage main gear box each components parameter computation and the selection process, and through computation examination. The design mainly includes: Main gear box structure choice, host, driven bevel gear's design, bearing's examination. The main reducer in the  transmission lines  used to reduce vehicle speed, increased the torque , it is less dependent on  the bevel of more gear drive of less bevel gear . Purchase of the longitudinal engine automobiles, the main bevel gear reducer also used to change the driving force for the direction of transmission.
Key words: Truck；Two-stage Main Reduction Gear；compensating gear；Gear；Check
