静压气浮导轨组件装置的设计
摘  要
采用气体润滑技术设计出的一套空气静压导轨组件装置。该组件可以立、卧式放置，具有多种机械安装接口，能在各种不同结构和要求的加工及测量设备中安装使用。对该组件的整体结构进行了设计和论证，经计算和测试本设计的组件总体性能良好，完全达到了所要求的设计目的。

关键词：静压导轨；滚珠丝杠副；气动平衡；步进电动机

Design and Analysis of Super-pressurized Gas
Hydrodynamic Guides Package
Abstract
A suit of modular gas hydrodynamic guides package was developed by tech- nique of air lubrication．This package has various machinery installation interfaces ,which can be placed with standing or lying ,can be used in the machining and measure equipments with different structure and request .The design and verification was carried on the whole structure of this package .The overall performance of the module is fine after experimental and achieve completely the anticipated design goal.

Key Words: Hydrodynamic Guides; Ball Screw ; Pneumatic Balance ; Step Moter
