Tilting mechanism is to achieve one of the main steelmaking production equipment, which is characterized by a large dump Moment, gear ratio, starting and braking frequently and withstanding greater dynamic load. Converter tilting mechanism works in harsh working environments, more slag dust and high temperatures. Thus their reliability and longevity for the safe operation of the equipment throughout the converter has a very significant impact. Adaptation to obtain a low rotational speed of the drive requires a large reduction ratio. Great weight converter furnace, plus loading weight, etc., the entire weight of the part to be tilting up hundreds of tons or thousands of tons. BOF furnace steel smelting a time, usually only four minutes later. Converter tilting mechanical work belongs to "start working system." In addition to the basic institutions to withstand static loads, but also to withstand dynamic loads due to start, braking caused. This dynamic load in the mouth skimming operation, more than twice its value even to static loads. Kai, the amount of braking complex, dynamic cut withstand greater load. As the steelmaking process low, heavy and harsh working conditions, coupled with the start, brake frequently, especially on a different way to start the motor on the dynamic behavior of the converter. With the converter tilting BOF steelmaking machinery popularization and development also continues to develop and improve, there have been various types of tilting the device. With torsion bar stopper buffer full hanging tilting mechanical, diagonally arranged into four main transmission system of a reducer drive one at the center of the second gear, so as to drive the rotary converter work performed. This paper converter tilting mechanism gives a brief introduction. Introduction tilting mechanism structure, design principles, the basic design parameters, as well as several forms of structure and configuration of the drive tilting mechanism and the transmission format.
Keywords: converter; tilting mechanism; pour Moment; transmission system；
Resilient mounting

目  录
1绪论 1
1.1转炉研究的背景及意义 1
1.2转炉炼钢工艺流程 2
1.3转炉倾动机构的设计原则 3
1.4国内外研究现状和发展趋势 3
1.4.1国外转炉倾动装置的研究现状和发展趋势 3
1.4.2 国内转炉倾动装置的研究现状和发展趋势 4
1.5 转炉倾动机构主要研究内容及方法 5
2转炉倾动机构总体方案的确定 6
2.1倾动机构的配置形式的比较与选择 6
2.2倾动机构的驱动的电机的选择 10
2.3倾动机构减速器的设计方案 11
2.4联轴器、齿轮、轴、轴承、制动器的选择 11
3转炉倾动力矩的计算 12
3.1倾动力矩的组成部分 12
3.2确定转炉炉型 14
3.3确定转炉重心 19
3.4确定预设耳轴位置 23
3.5计算炉液力矩与空炉力矩 23
3.6确定耳轴摩擦力矩 26
3.7运用Excel绘制倾动力矩表格 27
3.8确定最佳耳轴位置 28
3.9确定修正后的转炉倾动力矩 29
3.10绘制倾动力矩曲线图 31
4电动机、制动器及联轴器的设计与校核 31
4.1 电机容量计算与确定电机型号 31
4.1.1确定电机型号 31
4.1.2电动机工作制度值及发热值的校核 32
4.1.3电动机的过载校核 33
4.1.4确定启动时间 34
4.2 联轴器的计算与选择 35
4.3制动器的计算与选择 36
4.3.1制动器的选择计算 36
4.3.2制动时间校核 38
5齿轮传动系统的设计计算 38
5.1分配传动比 38
5.2运动以及动力参数计算 39
5.3齿轮传动设计 41
5.4其它齿轮设计计算 48
5.5齿轮的校核 49
6轴及轴承的设计计算 50
6.1轴材料的确定 50
6.2轴的设计计算 50
6.3轴的校核 55
6.4轴承的校核 59
7扭力杆系统的设计 61
7.1 扭力杆缓冲止动装置 61
7.2 扭力杆设计计算 62
7.2.1扭力杆直径和曲柄半径的确定 62
7.2.2 安全座空隙的选择 62
8 设备的可靠性和经济评价 63
8.1 设备的可靠性 63
8.1.1设备平均寿命 63
8.1.2 可靠度的计算 64
8.1.3 机械设备的有效度 64
8.2 设备的经济评价 66
8.2.1 投资回收期 66
8.2.2 盈亏平衡分析 67
    结    论 69
致    谢 70
参考文献 71
