Φ140mm轧管机侧压进系统设计
摘要
轧管机是生产无缝钢管的主要设备之一，由其名称就可判断其最主要的用途就是钢管的轧制。而在轧制过程中，侧压进装置必不可少，因为其对轧辊的调节将影响无缝钢管的生产质量。本课题利用链传动、蜗杆传动等基本原理，通过计算选取各机械设备的参数，选择并校核了电机，对液压缸进行了选择与校核。分配了传动比，校核了侧压螺丝的强度，进而设计蜗杆减速器，对蜗杆轴进行了设计计算及强度校核。通过进一步计算选取了联轴器、轴承和键的型号，使侧压进装置各项指标符合要求。
关键词：电动机的选择；液压缸；链传动；蜗杆传动；校核等
Φ 140 mm rolling machine pressure tube into the device

Abstract
Tube rolling mill is one of the main equipment of the production of seamless steel pipe, the name can be judged by its main purpose is the steel tube rolling. And in the rolling process, sidewall compression inlet device is essential, because the roll adjustment will affect the seamless steel pipe production quality. This topic use the chain transmission, worm drive and other basic principles, through the calculation and selection of the parameters of the mechanical equipment, select and check the motor, the hydraulic cylinder to select and check. Allocation of transmission ratio, the strength of checking the pressure screw, and design of the worm reducer, the design calculation and strength check of the worm shaft. Through further calculation of selected couplings, bearings and key models, the pressure feeding device the indicators meet the requirements.
Keywords:;The selection of motor;The hydraulic cylinder;Worm drive;Chain drive;
