冷轧带钢夹送矫直装置设计
摘要
随着国民经济的快速发展和生产规模的不断扩大，客户对钢材的质量和精度要求越来越高，大多数钢材必须经过矫直才能满足客户需求。矫直质量已经成为衡量产品竞争力的重要标准。在这种背景下，矫直技术得以迅速发展，应用也越来越广泛。辊式矫直机是目前应用最为广泛的一种矫直机。也是矫直技术发展最为完善的一种矫直机。本文中所设计的矫直机是五辊夹送矫直机组。针对冷轧带钢矫直，进行矫直力，矫直力矩，矫直功率，夹送各装置和零件校核计算。并根据给定的数据进过计算选出所需电机等传动装置。文中所涉及的夹送矫直机在经过一系列设计之后，依据工作原理，还要校核主要零件强度，以保证所设计的机械能够满足实际生产。最后还要结合技术经济环保分析，进行装置评估。
关键词：冷轧带钢五辊夹送矫直机；矫直辊；矫直力；矫直力矩；夹送辊；零件校核
Design of cold-rolled strip pinch straightening device
窗体底端
With the rapid development of national economy and the continuous expansion of production scale, customers on the quality and accuracy of steel increasing, most of the steel must be straightened in order to meet customer needs. Straightening has become an important measure of the quality of product competitiveness. In this context, straightening technology developed rapidly, applications are increasingly widespread. Roller leveler is currently the most widely used as a leveler. Straightening technology is the most perfect kind of leveler. Herein designed leveler five pinch roller straightening unit. For cold-rolled strip straightening, straightening force, the straightening moment, straightening power, pinch each apparatus and parts checking calculations. And according to the given data into the selected desired by calculating the motor and other gear. This paper involved pinch leveler After a series of design, based on the principle, but also to check the strength of the main parts, in order to ensure that the design of machinery to meet the actual production. Finally, environmental protection but also with technical and economic analysis, device evaluation.
Key words:Cold-rolled strip pinch five roller straightening machine; straightening roll; straightening force; straightening moment; pinch rollers; parts checking
窗体底端
