摘要

整机结构主要由电动机、机架、传动带、偏心轮构成。由电动机产生动力通过带轮减速器将需要的动力传递到带轮上，带轮带动V带，从而带动整机装置运动
本论文研究内容摘要：
(1)板栗去皮机总体结构设计。
(2)板栗去皮机工作性能分析。
(3)电动机的选择。
(4)对板栗去皮机的传动系统、执行部件及机架设计。
(5)对设计零件进行设计计算分析和校核。
(6)绘制整机装配图及重要部件装配图和设计零件的零件图。

关键词：板栗去皮机，结构设计
 Abstract

The structure is mainly composed of the motor, frame, transmission belt, an eccentric wheel. The power generated by the motor through the belt wheel speed reducer will need to transfer the power to the belt wheel, belt wheel drive V, so as to drive the movement of the whole device
Abstract this dissertation studies:

(1) the overall structure design of chestnut peeling machine.

(2) analysis of chestnut peeling machine performance.

(3) the choice of motor.

(4) transmission system, execution unit and frame design of chestnut peeling machine.

(5) the design of parts of the design calculation and check.

(6) the assembly drawing and parts drawing assembly drawings and parts drawings design.

Keywords: chestnut peeling machine, structure design
