ABSTRACT
  High-speed color toothbrush tufting machine is improve efficiency and advanced processing equipment of toothbrushes.Greatly improved production efficiency,production quality, production varieties. Efficiency than the original manual operations increased by 6 to 7 times，completion 15000 amounted to 20000 Toothbrush in every day，great to meet the needs of the market.and achieved good economic.The purpose of this project is to make the link between each process, and enhance the degree of mechanization to reduce labor participation, both to reduce costs and to improve the efficiency of a production.
  After considering a combination of the above,I will be the topic of this design is the high-speed color toothbrush tufting machine mechanical structure design.Design of the main uses CAD, Solidworks and other engineering drawing software for drawing and structural analysis. And some important components necessary calculations and verification.



Key words:  toothbrush-hair planting;Design;Structural Analysis











目录
中文摘要
ABSTRACT
第一章 绪论 1
1.1 课题背景和研究意义 1
1.2 近代牙刷的发展历程 2
1.3 国内外植毛机的发展现状 2
1.4 本课题的立题依据 3
1.5 本课题研究的内容 4
第二章 植毛机的工作原理 5
第三章  植毛机总体方案选择 7
3.1植毛机的技术进展 7
3.2植毛机的结构 9
第四章  植毛机的总体结构及组成部分结构 11
4.1 植毛机的布局 11
4.2 刷柄自动装夹设计 12
4.3 刷柄自动运行机构设计 13
4.4 自动分丝机构设计 14
4.5 自动送铝片、及自动切断机构设计 16
4.6自动钩丝机构的设计 17
4.7 本章小结 17
第五章  植毛机零件的设计计算 18
5.1系统的运动分析 18
5.2主轴箱电机的选择 19
5.3皮带的选择 21
5.4主轴的设计计算 23
5.5送丝嘴运动分析计算 28
5.6 送铝片运动分析计算 30
5.7 铝片切断运动分析计算 32
5.8 送丝凸轮的设计计算 35
5.8.1送丝凸轮的基本尺寸 35
5.8.2送丝凸轮的理论轮廓 35
5.8.3送丝凸轮的工作轮廓 36
5.9 本章小结 38
第六章 植毛机控制系统 39
6.1牙刷植毛机数控系统工作原理及其总结构设计 39
6.2 PLC 控制电路图 41
6.3 I/O扩展电路 42
参考文献 43
致谢 44


机械毕业设计|论文
