摘    要

随着科技步伐的加快，液压技术在各个领域中得到了广泛应用，液压系统已成为主机设备中最关键的部分之一。但是，由于设计、制造、安装、使用和维护等方面的因素，影响了液压系统的正常运行。因此，了解系统工作原理，懂得一些设计、制造、安装、使用和维护等方面的知识，是保证液压系统能正常运行并极大发挥液压技术优势的先决条件。
本文主要研究的是液压传动系统，液压传动系统的设计需要与主机的总体设计同时进行。设计时，必须从实际情况出发，有机地结合各种传动形式，充分发挥液压传动的优点，力求设计出结构简单、工作可靠、成本低、效率高、操作简单、维修方便的液压传动系统。
本文介绍了国内外水下作业工具、水下作业系统、常用的水下切割方法和管道切割的发展现状，归纳和总结了国内外金刚石绳锯机的发展状况，提出了水下海底管道金刚石绳锯切割机进行海底油气管道切割的思路,设计出绳锯机的液压传动控制系统，并对动力源的主要技术参数进行了计算和校核。本论文主要完成了如下工作：
1、 完成了水下海底管道金刚石绳锯切割机机方案确定与分析设计。
2、 完成了水下海底管道金刚石绳锯切割机液压系统的设计。
3、 完成了绳锯机的液压系统动力源，计算了液压执行元件的主要参数，并对绳锯机的夹紧装置、张紧装置、进给装置进行了设计。
4、 设计出水下海底管道金刚石绳锯切割机液压系统原理图，并对液压动力源的主要技术参数进行了计算和检验，选择了液压泵、电机、控制阀等元件。
5、 完成了水下海底管道金刚石绳锯切割机专用液压系统设计。

关键词：水下海底管道金刚石绳锯切割机，金刚石绳锯切割机，设计


Abstract

With the development of the technology, hydraulic technology has been widely used in various fields, and hydraulic system has become one of the most important parts of the host equipment.. However, due to the design, manufacture, installation, use and maintenance of factors, the impact of the normal operation of the hydraulic system. Therefore, to understand the working principle of the system, to understand some of the design, manufacture, installation, use and maintenance of knowledge is a hydraulic system to ensure normal operation and great play a prerequisite for hydraulic technology advantage.
This paper mainly studies the hydraulic transmission system, the design of hydraulic drive system and the overall design of the host. Design, we must proceed from the actual situation, and organically combined with various forms of transmission, give full play to the advantages of hydraulic transmission, strive to design a simple structure, reliable work, low cost, high efficiency, simple operation, convenient maintenance hydraulic transmission system.
Is introduced in this paper the development status of the at home and abroad work tools, underwater operation system, common water cutting method and cutting the pipe, and sums up the developing situation at home and abroad of diamond wire saw, put forward the idea of underwater submarine pipeline diamond wire saw cutting machine for cutting the seabed oil-gas pipeline design wire saw machine hydraulic drive and control system, and main technical parameters of the power is calculated and checked. This thesis mainly completes the following work:
1, the underwater submarine pipeline diamond wire saw cutting machine plan and analysis design.
2. The hydraulic system design of the diamond wire saw cutting machine for underwater submarine pipeline is accomplished..
3, the power source of the hydraulic system of the rope saw is finished, and the main parameters of the hydraulic execution element are calculated, and the clamp device, the tensioning device and the feeding device of the rope saw machine are designed..
4, design of underwater submarine pipeline diamond wire saw cutting machine hydraulic system principle diagram, and calculating and checking the main technical parameters of the hydraulic power source, choose the hydraulic pump, motor, control valves and other components.
5. The design of the special hydraulic system for the diamond wire saw cutting machine of underwater submarine pipeline is accomplished..

Key word:underwater submarine pipeline diamond wire saw cutting machine, diamond wire saw cutting machine, design
