FRP Traction machine design

This thesis introduces the process of making glass fiber reinforced the implementation of the dynamic components. Glass fiber wire and glass fiber reinforced plastic molded products campaign has been powered in part by the traction. The realization of the process depends mainly on the role of the spring tension by compacting extrusion friction generated by the chain-axis motor driven exercise, and the processing of the glass pipe out there is thread through the installation of the chain pipe chain plate and glass of under compression between the friction generated by moving forward. At the same time, pressed the spring in order to prevent too tight to the detriment of too much friction traction movement,
Therefore chose the pneumatic components, pneumatic components through the stretch to overcome the spring pressure to release the traction free.
Part of the traction chain drive is the core of the design, and parallel in order to achieve traction, the chain drive is a special form of chain drive, it is the role of parallel transmission, unlike the previous slow down the chain drive is chain drive, in this only to achieve parallel momentum transfer.

Key words:

Traction  Spring   Friction    Pneumatic components   Chain Drive  Parallel transmission
