摘要

本文根据高速高精密数控车床的特点，在查阅了相关文献及大量资料后进行了详细分析，对液压系统方案拟定，最终设计出了较为适合的液压系统。在查阅大量资料后对国内外范围内高速高精密数控车床的发展以及与液压技术的结合做了介绍。同时阐述了高速高精密数控车床的应用领域与在我国的发展现状，并对今后的发展趋势做了讨论。
本设计首先对车床自身结构进行了分析，通过计算及查阅文献选定了各主要部件的主要工作参数。然后根据机床的功能需求对液压系统进行了分析，最终确定了液压系统的设计方案。先后进行了工况分析、分析计算优选各主要液压系统、使用AutoCAD对液压系统原理图进行了绘制、对各液压回路方案进行确定、选择了液压元件并对系统的部分零件进行了设计。 最后对设计进行了验算以确保该设计在实际工作中能达到预期。

关键词：数控机床；高速高精密数控车床；液压系统；AutoCAD



ABSTRACT

In this paper, according to the characteristics of high speed and high precision CNC lathe, a detailed analysis is made after consulting the relevant literature and a large amount of data. The hydraulic system is finally designed and a more suitable hydraulic system is designed. After consulting a large amount of data, the development of high speed and high precision CNC lathes and the combination of hydraulic technology at home and abroad are introduced. At the same time, the application field and development status of high speed and high precision CNC lathe in China are expounded, and the development trend in the future is discussed.
Firstly, the structure of the lathe is analyzed, and the main working parameters of the main components are selected through calculation and literature review. Then, according to the functional requirements of the machine tool, the hydraulic system is analyzed, and the design scheme of the hydraulic system is finally determined. The main hydraulic system was selected and optimized, the hydraulic system was drawn by AutoCAD, the hydraulic circuit scheme was determined, the hydraulic components were selected and some parts of the system were designed. Finally, the design is checked to ensure that the design can achieve the desired results in practical work.

Key words: CNC machine tools; high speed and high precision CNC lathe; hydraulic system; AutoCAD
