摘要：本文主要介绍了上下料用机械手的设计过程，它包括了对于整个系统的工作要求和情况的分析，通过系统的工作过程确定整个液压系统的结构设计。分析整个循环过程，确定系统工作原理图，根据系统参数要求选择标准的液压元件，完成液压系统的装配图。液压集成块作为现在液压系统的主要部件，当前液压集成块应用开发受到了国内外液压界的广泛重视，液压集成块的CAD的研究与开发已为液压工程设计提供了有力的支持，在对机械手液压系统集成块设计过程中，能够与实际的加工工艺相结合。并且对现在的液压集成块的CAD技术有很好的认识。
关键词：工业机械手，驱动，集成块，原理
Design of The Industry Manipulator
Abstract: This text introduce upper and lower material spend design process of manipulator , it include to whole job requirements and analysis of situation of system mainly, confirm the whole structural design systematic in hydraulic pressure through the working course of the system. Analyse whole cyclical process , confirm systematic operation principle picture , require the hydraulic pressure component of the standard for selection according to systematic parameter, finish the installation diagram systematic in hydraulic pressure. Hydraulic pressure integrate piece as now main part , hydraulic pressure of system , hydraulic pressure at present integrate pieces of application and development receive domestic and international hydraulic pressure extensive attention of circle, hydraulic pressure integrate research and development of CAD of piece already offer effective support for engineering design of the hydraulic pressure, while design the system integration one of hydraulic pressure of the manipulator, can combine with real processing technology . And CAD integrating one to the present hydraulic pressure has very good understanding.
Keyword: Industry manipulator ,Drive , Hydraulic manifold block , Elements
