设计简介
咖啡粉枕式包装机总体设计及计量装置设计
摘要：本设计是咖啡粉枕式包装机，课题来源于盐城市盛和轻工机械厂。主要设计内容为：咖啡粉枕式包装机的包装原理设计，计量装置工作原理，包装的总体结构设计及计量装置的总体结构设计。
本包装机考虑到咖啡粉的特性和包装袋的要求以及该厂的实际生产条件，选用凸轮作为包装袋封口和牵引的主要机构；同时采用量杯式计量，并且通过开闭盖销对活动底盖的位置限制来实现量杯下料口的开闭，从而保证计量过程的稳定。
本设计对咖啡粉包装的传动路线和包装路线进行了分析，并对传动比进行合理分配，解决了咖啡粉快速、稳定、自动包装等问题。实现了包装机的预期效果。
关键词：包装机；计量装置；咖啡粉
The Design of Overall Packing Machine and Measurement Device for Coffee Powder
Abstract : The design of overall packing machine for coffee powder ,subjects come from Yan cheng sheng he light machinery factory . The design of the principle of the packaging for coffee powder , measuring device principle, the overall structure of packaging design and the overall measurement device structure design.
The packaging machine for coffee powder accounts into characteristics and requirements of the packaging plant and the actual production conditions, cam was taken into account during the design; While using measuring cup meter, serviced through the opening and closing of activities bottom cover the location restrictions to achieve the mouth of measuring cup opening and closing, measurement process so as to ensure stability.
The design of the coffee powder packaged transmission and packaging line analysis and drive reasonable allocation. Resolved quickly coffee powder, stability,automatic packaging problem and so on . Implementation of the packaging machine achived expected goal .
Key words : Packaging; Metering devices; Coffee Powder
目 录
