摘  要

  本文主要介绍了温控器垫块注塑模设计，塑料成形工艺以及注塑的过程，也对注塑机也进行了一些简单的介绍。注塑模设计的主要过程有：塑料制品的工艺分析，型腔数目的确定，注塑机的选择以及模具的结构设计。模具的结构设计包括：浇注系统的设计，成型零件设计，导向机构设计，侧面分型机构设计，脱模机构设计，冷却机构设计以及排气系统设计。本文设计的是采用一模4件的模具结构，本文对模具的各部分零件进行了设计与计算。本文给出了详细的设计过程及装配图。

关键词：温控器垫块；成型；注塑模；工艺

Abstract

This paper mainly introduces the design of a mold temperature controller pad, process and the plastic injection molding process, the injection molding machine is introduced. The main injection mold design process: the process analysis of plastic products, to determine the number of cavity structure design, the choice of injection molding machine and mold. The structural design of mold include: the design of gating system, forming part design, design oriented, side parting mechanism design, demoulding mechanism design, cooling system design and exhaust system design. In this paper, the design of the die structure using a mold is 4 parts in this paper, all part of part in mould design and calculation. This paper gives the design process in detail and assembly drawings.

Keywords: temperature controller block; injection mold; molding process;
